Card Issuing Machine TTCE-K100
Card dispenser with IC/RFID card reader & writer, magnetic card reader. Multi-function card dispenser, supporting IC card, magnetic card, RF card, SIM card. A very stable multifunctional card issuing machine that supports multiple types of cards and different card thicknesses, selling well overseas.
- Card dispensing with card reading/writing function
- IC/FRID card read/write, magnetic card read only
- By changing the channel space can accept all the card thickness between 0.2-2.0mm
- Max loading 400pcs card thickness 0.76mm compare standard 150pcs cards
Features of TTCE-K100
- Card dispensing with card reading/writing function
- IC/FRID card read/write, magnetic card read only
- By changing the channel space can accept all the card thickness between 0.2-2.0mm
- Max loading 400pcs card thickness 0.76mm compare standard 150pcs cards
Details of TTCE-K100
K100 supports bidirectional magcard read, IC card read and write, RFID card read and write protocol, and supports more card thicknesses. Modular install structure makes it convenient for clients to customize and maintain machine. Smart design and parts assembled with best quality make it fresh in appearance, and precision meets or overpass same type products all over the world. Excellent circuit design takes multipleprotection into consideration. It is one of few card issuing, read/write equipment integrated with read/write, issuing card function. It supports IC card type more than other same product.
Specification of TTCE-K100
| Card Type | IC card: ISO7816-1、2、3、4 standard Support T=0,T=1 CPU Card Support T=0,T=1 PSAM Card Contactless card: ISO/IEC 14443 Type A & Type B Support Mifare 1 S50,S70,UL card,Mifare Plus,Mifare Desfire Magnetic card: ISO7810, ISO7811 -(1-6), ISO7812, ISO7813 And ISO15457 |
| Card Specification | Material: Paper card and PC card Width:54 ± 0.5 mm(W) Length: 85 ± 0.5 mm Thickness: 0.2-2.0mm |
| Power Supply | DC24V |
| Operation Current | Idle:<100mA Peak:<3000mA |
| Interface | RS232/USB |
| Card Hopper Capacity | 150 pcs standard cards at thickness of 0.76mm (Note: stacker capacity can be extended to 300pcs or 400pcs) |
| Alert Lamp | Card entry alert Few card alert Power on alert IC card power on alert |
| Environmental Conditions | Operation Temp: -5 ℃ to 50℃ Operation Humi: 0～90% (Relative Humidity) |
| Life Time | Drive parts: 500,000cycles Magnetic head: 800,000cycles IC card contact: 300,000cycles |
| Certified | |
| Weight | About 3.5kg |
Application of TTCE-K100
In banking and financial services, the TTCE-K100 automates ATM card issuance and self-service banking solutions. Public transportation systems use it for quick ticket and travel card distribution, improving passenger convenience. Access control systems in hotels, offices, and events rely on it for issuing secure entry cards. In retail and loyalty programs, it enables instant membership and gift card dispensing. Additionally, it supports parking and ticketing kiosks, ensuring fast and reliable card distribution.
Our Advantages
With an experienced R&D team, We can satisfy the diverse customization needs of our customers.
Expert Team and Customized Services
Our professional team excels in collaboration, delivering high-quality results while offering customized solutions to meet each customer’s unique needs and specifications.
Comprehensive One-stop Solution
We provide a complete package, from initial manufacturing to ongoing support, including tailored ODM and OEM services, ensuring a seamless experience.
Global Export Experience
With 23 years of development, our modules are exported worldwide, bringing extensive market insights and customer experience across global markets.
