Barcode Card Dispenser Module TTCE-K710

Membership card and gift card dispenser barcode card dispenser module barcode card issuer can be used in parking lot fee collection, amusement park membership cards, hospital medical cards, membership cards, etc.

Patented visual 6-position card distance adjustment technology can adapt to the issuance of cards of different thicknesses.
The barcode reading module can be adjusted up and down, left and right to ensure that the best angle can be used to accurately read the one-dimensional and two-dimensional code information.
The special card rubbing wheel structure design ensures the one-time card output success rate, prevents double card output and can adapt to certain deformed card issuance.
The card box capacity can be customized and increased.
Multiple intelligent reminder alarm states such as card pre-empty, card empty, and card issuance failure.

Get Free Quote

Features Description Specification Application Why Choose Us

Features of TTCE-K710

RFID Card Read & Dispense Module: Supports secure card transactions with an RS232 interface.
Adjustable Card Thickness: Accepts cards between 0.2mm and 2.0mm, ensuring versatility.
High Card Capacity: Holds up to 300 cards (0.76mm thickness) for continuous operation.
Removable Collection System: Allows excess cards to drop to the kiosk bottom for extended storage.
Seamless Integration: Compatible with self-service kiosks, banking terminals, and access control systems.

Details of TTCE-K710

TTCE-K710 is a barcode reader that supports issuing a variety of cards. This product adopts industrial-grade design, with a surface paint treatment, and has good wear and corrosion resistance. It is suitable for various harsh environments such as high and low temperatures and dust. Its card issuing principle is anthropomorphic friction card issuing, which has very good adaptability to various deformed cards. A movable card box installation position is reserved for more effective card management. In terms of issuing cards of different thicknesses, this product has a unique patented technology-a six-level card distance adjustment function. The precision of CNC ensures the absolute consistency, simplicity and standard of the card distance.

Specification of TTCE-K710

Card Type	Barcode Card
Card Specification	Material: paper card and PC card Width: 54 ± 0.5 mm(W) Length: 85 ± 0.5 mm Thickness: 0.2 ～2mm
Power Supply	24V/3A
Working Current	Idle: <120mA Peak: <2000mA
Interface	RS232
Card Hopper Capacity	130 pcs standard cards at thickness of 0.76mm (Note: stacker capacity can be extended to 300 pcs)
Alert Lamp	Card entry alert Few card alert Power on alert
Environmental Conditions	Operation temp: -5 ℃ to 55℃ Operation humi: 30～90% (relative humidity)
Life Time	Drive parts: 500,000cycles
Weight	About 2.5kg

Application of TTCE-K710

In banking and financial services, the TTCE-K710 automates ATM card issuance and RFID-based transactions. Public transportation systems use it for fast ticketing and travel card distribution, improving passenger convenience. Access control systems in hotels, offices, and event venues rely on it for secure RFID entry card issuance. In retail and loyalty programs, it enables the quick issuance of membership and gift cards. Additionally, parking and ticketing kiosks benefit from its efficient RFID card dispensing capabilities.
